BFT BOTTICELLI SMART BT A850 Garage Door Opener UAE

High-Speed Smart Garage Door Automation for Residential & Commercial Applications

The BFT BOTTICELLI SMART BT A850 Garage Door Opener is a premium Italian-made 24V automation system designed for sectional garage doors with a maximum surface area of 13 m². Featuring powerful 850N tractive force, smart connectivity and intensive-duty performance, this advanced garage door motor delivers fast, reliable and secure automation for residential and commercial properties across the UAE.

Powered by a high-performance 24V motor and managed through the intelligent VENERE BT A DIS control unit, the BFT BOTTICELLI SMART BT A850 provides rapid door operation with opening speeds up to 210 mm/sec using chain rail systems and up to 240 mm/sec using belt rail systems. The fast-opening technology minimizes waiting times while ensuring smooth and efficient door movement.

Designed for intensive daily use, the system supports up to 50 operating cycles per day and incorporates advanced D-Track intelligent force management technology for obstacle detection and enhanced operational safety. The encoder-based positioning system ensures precise movement control and accurate stopping performance.

With smart interconnectivity, ultra-low standby power consumption of less than 1W and reliable mechanical locking protection, the BFT BOTTICELLI SMART BT A850 is an ideal solution for villas, commercial garages, warehouses and parking facilities throughout Dubai, Sharjah, Abu Dhabi and all UAE.

BFT BOTTICELLI SMART BT A850 Features

• Suitable for sectional garage doors up to 13 m²
• 850N tractive force and thrust capacity
• Original BFT Italian garage automation technology
• 24V high-performance motor system
• VENERE BT A DIS intelligent control unit
• Opening speed up to 210 mm/sec (chain rail)
• Opening speed up to 240 mm/sec (belt rail)
• Smart interconnectivity support
• D-Track intelligent safety management system
• Encoder positioning technology
• Mechanical locking protection
• Steel cord or cable emergency release
• Ultra-low standby consumption below 1W
• Designed for intensive operation

Applications

• Residential villa garages
• Luxury home garage doors
• Commercial garage entrances
• Warehouse garage doors
• Apartment parking facilities
• Business and office garages
• Automated sectional garage doors

Technical Specifications

• Model: BFT BOTTICELLI SMART BT A850
• Product Code: P915212 00005
• Control Unit: VENERE BT A DIS
• Nominal Voltage: 24V
• Power Consumption: 200W
• Standby Consumption: Less than 1W
• Tractive Force and Thrust: 850N
• Maximum Door Surface Area: 13 m²
• Maximum Opening Speed (Chain Rail): 210 mm/sec
• Maximum Opening Speed (Belt Rail): 240 mm/sec
• Daily Movements: 50 Cycles
• Limit Switch Type: Encoder + Mechanical Stop
• Slowdown Function: Yes
• Locking System: Mechanical
• Release System: Steel Cord or Cable
• Impact Reaction: D-Track
• Protection Rating: IP20
• Operating Temperature: -20°C to +60°C
• Interconnectivity: Yes

Why Choose BFT BOTTICELLI SMART BT A850?

• Original Italian garage automation technology
• High-speed opening performance
• Powerful 850N motor system
• Smart connectivity and advanced control features
• Ultra-low standby energy consumption
• Suitable for intensive daily operation
• Professional installation and technical support available across UAE
