LD202 Dual Channel Vehicle Loop Detector UAE
Price Select Available OptionIn Stock
LD202 12-24V AC/DC Dual Channel Loop Detector
The LD202 Dual Channel Vehicle Loop Detector is a professional two-channel inductive vehicle detection system designed for automatic parking barriers, gates, access control and traffic management systems. The dual-channel design allows two inductive vehicle loops to be monitored from a single detector.
Operating from a 12-24V AC/DC power supply, the LD202 can be used for vehicle presence detection, free-exit control, safety loops, access control triggering and directional vehicle detection. It is suitable for residential, commercial and industrial vehicle access installations throughout the UAE.
LD202 Dual Channel Loop Detector Features
- Dual channel vehicle loop detector
- Model: LD202
- 12-24V AC/DC power supply
- Monitors two inductive vehicle loops
- Pulse and presence relay operation
- Adjustable sensitivity settings
- Selectable operating frequency
- Vehicle presence detection
- A-B directional logic
- Extended timing functions
- LED status indication
- Loop fault indication
- Suitable for automatic gates and parking barriers
- 11-pin connector mounting
LD202 Technical Specifications
| Model | LD202 |
| Product Type | Dual Channel Vehicle Loop Detector |
| Detection Technology | Inductive Loop Vehicle Detection |
| Detection Channels | 2 Channels |
| Number of Loops | 2 Inductive Loops |
| Power Supply | 12-24V AC/DC |
| Relay Modes | Pulse & Presence |
| Sensitivity | Adjustable |
| Frequency Selection | Selectable |
| Directional Detection | A-B Logic |
| Status Indication | LED Indicators |
| Mounting / Connection | 11-Pin Connector |
| Application | Gates, Parking Barriers & Vehicle Access Control |
Dual Channel Vehicle Detection
The LD202 provides two vehicle detection channels, allowing two inductive loops to be connected to one detector. The two-loop configuration provides additional flexibility for parking barrier, automatic gate and vehicle access applications.
LD202 for Parking Gate Barriers
The LD202 can be integrated with compatible automatic parking barrier systems. Vehicle detection signals can be used for barrier opening, vehicle presence monitoring, safety loops and other supported automation functions.
LD202 for Automatic Gates
The detector can also be connected to compatible sliding gate and swing gate control boards. Relay outputs from the loop detector provide vehicle detection signals to the automation system.
Free Exit Vehicle Detection
The LD202 can be used as a free-exit vehicle detector. When a vehicle approaches the exit loop, the detector can provide a relay signal to a compatible gate or parking barrier controller to initiate an opening command.
Safety Loop Detection
An inductive loop can be positioned beneath or close to an automatic barrier arm or gate movement area. When a vehicle is detected, the loop detector can provide a safety signal to a compatible automation controller according to the system configuration.
A-B Directional Logic
The dual-channel configuration allows the LD202 to support A-B directional logic. When two loops are installed in sequence, the detector can determine vehicle movement according to the order in which the loops are activated.
This feature is useful for compatible access control, vehicle counting and traffic management applications.
Adjustable Sensitivity
The LD202 provides adjustable sensitivity so installers can configure vehicle detection according to the loop dimensions, vehicle types and installation conditions.
Selectable Loop Frequency
Selectable operating frequencies help reduce interference between inductive loops installed close to each other. Correct frequency configuration is particularly important in installations using multiple vehicle detection loops.
LED Status & Fault Indication
LED indicators provide visual information about detector power, vehicle detection and loop condition, helping installers during setup, testing and troubleshooting.
LD202 Vehicle Loop Detector Applications
- Automatic parking barriers
- Sliding gate automation
- Swing gate automation
- Free-exit vehicle detection
- Safety loop detection
- Vehicle access control systems
- RFID vehicle access systems
- Vehicle counting applications
- Directional vehicle detection
- Commercial parking facilities
- Residential communities
- Warehouses and factories
- Industrial entrances
- Traffic management systems
LD202 vs Single Channel Loop Detector
A single-channel loop detector monitors one inductive loop, while the LD202 Dual Channel Loop Detector can monitor two loops. The dual-channel configuration is useful when an installation requires separate detection positions, directional detection or additional vehicle control functions.
LD202 Loop Detector Installation in UAE
Professional LD202 Dual Channel Vehicle Loop Detector installation in UAE is available for automatic gates, parking barriers and vehicle access control systems.
Loop cutting, loop cable installation, detector wiring, configuration and testing are available across Dubai, Sharjah, Abu Dhabi, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain and Al Ain.
Buy LD202 Dual Channel Loop Detector in UAE
Looking for an LD202 Dual Channel Vehicle Loop Detector in UAE? Contact us for product supply, loop cable, installation and technical support.
Call or WhatsApp: +971 55 202 9347
